TVK-XE4-TH

DELL Optiplex XE4 MT With Anti-Vibration Kit, TVK – XE4 – TH/TV

GENERAL

OptiPlex XE4 PCs are type approved for marine usage when they are used in conjunction with TD Kits (anti-vibration Kits). TD Kits are designed for protection against vibration and shock caused by marine environments.

For XE4 Tower, there are TVK-XE4-TH (horizontal installation) and TVK-XE4-TV (vertical installation). The combination (XE4+TD Kits) can be efficiently used in various marine applications such as controlling, monitoring, loading, detecting, networking, etc.

KEY FEATURES

  • 12th Generation Intel Core i3 / i5 / i7 / i9
  • DDR5 memory for XE4 Tower
  • m.2 SSD up to 2TB, SATA HDD up to 4TB
  • Type Approved by ABS, BV, CCS, DNV, KR, LR, NK, IEC60945
  • IACS UR E10 & IEC60945 approved for wheel house installation
  • Windows 10, 11 pro (64 bit)

SPECIFICATIONS

GENERAL FEATURE
Section Specifications
CPU 12th Generation Intel® Core™ i3, i5, i7, i9
OS Microsoft Windows 10, 11 Pro/Home (64 Bit), Linux 20.04 LTS(64-Bit) (64-bit)
Memory DDR5 8GB 4400MHz (Up to 128GB)
Chipset Intel® Q670
Storage M.2 256GB NVME SSD (Up to 2TB)
Graphic Intel® UHD Graphics 730 for 12th Intel® Core™ i3, i5-12400
Intel® UHD Graphics 770 for 12th Intel® Core™ i5-12500, i7, i9
Networking (LAN) Intel i219LM Etherent
I/O 1 x USB 3.2 Type-C®, 1 x USB 2.0 with PowerShare
1 x USB 2.0, 2 x USB 3.2 Gen, 1 x Universal audio jack
3 x USB 3.2 Gen 1, 1 x USB 3.2 Gen 2, 2 x USB 2.0 with Smart Power On
1 x RJ45 Ethernet, 1 x Re-tasking line out/line in audio, 3 x DisplayPort 1.4a
1 x Header for remote power button
Optional: 1 x Video Port (VGA/DP/HDMI 2.0b/USB Type-C alt-mode, USB Add-in-card, Serial Add-in-card
Number of Bays (max) 1 internal 3.5” HDD
2 internal 2.5” HDD
1 internal slim ODD
Power Consumption 500W PSU
Dimension (PC with kit) 179(W) x 406(H) x 303(D) mm for TV Kit
377(W) x 223(H) x 303(D) mm for TH Kit
Weight (PC with kit) 8.00kg (±1kg)
Temperature Range Operating : 0℃ to 40℃
Non-Operating : -40℃ to 65℃
Humidity Range Operating : up to 95%
Non-Operating : up to 95%
Optical Drive Device 8xDVD-ROM 9.5mm ODD (Option)
8xDVD+/-RW 9.5mm ODD (Option)
SD Media Card Reader (Option)
Certification ABS, BV, CCS, DNV, KR, LR, NK, IEC60945
Warranty 36 months
